Details & Features

• Even-Heat True Convection
• Produces flawless results. The unique bow-tie design and convection fan ensure the inside of the entire oven is heated to, and stays at, the perfect temperature.
• Steam Rack
• Offers the ability to provide additional moisture to the inside of the oven, enhancing cooking results.
• 6.4 cu ft Capacity
• This electric slide-in range provides a large cooking capacity that easily handles multiple dishes at once.
• EasyConvect Conversion
• Takes the guesswork out of convection cooking by converting conventional settings for recipes to convection settings for you.
• FIT Guarantee
• Is our promise to flawlessly fit slide-in ranges designed for an existing cutout of 30" width, countertop depth of 24"-25", cabinet depth of 23"-24" and countertop height of 36".

• 5 Cooking Elements Including A Warm Zone - Provides five independent cooking surfaces that allow you to do more on your range. It features a triple cooking zone of 6, 9 and 12 inches, one 10 inch zone and two 6 inch cooking zones, plus a dedicated warming zone.
• Aqualift™ - Cleans your oven in less than an hour without odors and at a temperature below 200°F. This innovative system combines low heat with water to release baked-on spills.
• Storage Drawer - Adds additional storage space that's perfect for pots, pans and baking sheets.
• Glass Touch Controls - Offer an intuitive, easy-to-use touch screen experience.
• 4000W Broil Feature - Provides a variable temperature option, giving you complete control while you broil.
• Side Trim Accessory Kit - This optional accessory kit will cover damaged countertops and unfinished edges from an old slide- in range to make them beautiful again. Trim pieces come in black, white and stainless to seamlessly match your new range.

Tech Specs

Specifications
Dimensions
Capacity	6-2/5
Depth Closed Excluding Handles	26-3/8 in
Depth Closed Including Handles	28-7/8 in
Depth With Door Open 90 Degree	48-3/4 in
Height	36.0 in
Width	29-7/8 in
Configuration and Overview
ADA Compliant	ADA Height and Operation Compliant
Fuel Type	Electric
LP Convertible	No
Prop 65	CALIFORNIA RESIDENTS ONLY - WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov .
Range Type	Slide-in
Size	30 in
UL	UL
Appearance
Door Type	Metal & Glass
Handle Color	Stainless Steel
Handle Material	Metal
Handle Type	Towel Bar
Oven Details
Automatic Convection Conversion Temperature Adjust	Yes
Bake Element Power	3600W
Broiler Location	Top of Oven
Convection Element Type	Single-Fan
Convection Functions	Bake, Broil, Roast
Drawer Type	Storage Drawer
Hidden Bake Element	Yes
Interior Color	Grey
Number of Oven Lights	2
Number of Oven Racks	3
Number of Rack Guides	7
Oven Control Type	Electronic Touch
Oven Cooking System	Convection
Oven Interior Depth	20-5/8 in
Oven Interior Height	22-1/8 in
Oven Interior Width	24-1/8 in
Oven Light Type	Incandescent
Oven Rack Type	1 Max Capacity, 1 Standard, 1 Steam Rack
Power On Indicator Light	Yes
Cooktop Details
Center Rear Element-Burner Power	100W
Center Rear Element-Burner Size	6""
Cooktop Element Style	Radiant
Cooktop Surface Color	Black
Cooktop Surface Material	Ceramic Glass
Heating Element On Indicator Light	Yes
Hot Surface Indicator Light	Yes
Left Front Element-Burner Power	3000W/1950W/1050W
Left Front Element-Burner Size	12""/9""/6""
Left Front Element-Burner Type	Triple
Left Rear Element-Burner Power	1300W
Left Rear Element-Burner Size	6""
Left Rear Element-Burner Type	Hyper
Number of Cooking Element-Burners	5
Power Outage Compatible	No
Right Front Element-Burner Power	3200W
Right Front Element-Burner Size	10""
Right Front Element-Burner Type	Hyper
Right Rear Element-Burner Size	6""
Right Rear Element-Burner Type	Single
Details
Bake Element Power	3600W
Broiler Element Power	4000W
Convection Element Type	Single-Fan
Number of Rack Guides	7
Oven Cleaning Type	AquaLift® Self Clean
Electrical
Power Cord Included	No
Controls
Knob Color	Stainless Steel
Knob Type	Metal
Exterior
Oven Window Size	Large
Features
Power Outage Compatible	No
GDS
GPC Code	10003690
IsInvoiceUnit	true
IsOrderableUnit	true
Product Type	EA
UDEX	1100400623
isBaseUnit	true
isConsumerUnit	true
